Temperature sensor signal conditioning 4-20mA transmitters

Robert Owen produces instruments and instrumentation, for sensor signal conditioning and trend recording. Analog USB adapters, or USB A-D's; can measure voltage, current, and resistance; when the right signal conditioning is used. Recording instruments, such as the ROI-USB A-D, can be used to monitor a range of sensors and signals; to read: temperature sensors such as the RTD and the Thermistor, position and level sensors such as potentiometers, or high voltage through voltage isolators; by reading, current transmitter or isolation amplifier, signal conditioners.

Made in the USA!

Instrumentation Amplifiers	*Galvanic Isolators*	*Analog USB Adapters*
Sensor Signal Conditioning	*Voltage Isolation Amplifiers*	*USB A-D's*

4-20mA loop transmitters are used where weak sensor signals need to be connected long distances to PLC's or USB A-D's.	*Voltage isolation amplifiers used where analog signal noise suppression, ground loop elimination, or high voltage potential separation is needed.*	USB analog to digital converters are used where an XP PC is needed to measure analog sensor signals such as voltage, current, and resistance.
*RTD 4-20mA Transmitters* *Thermistor 4-20mA Transmitters* *Bridge Sensor 4-20mA Transmitters* *Potentiometer 4-20mA Transmitters* *mV 4-20mA Transmitters*	*Isolation Amplifiers*	*0-20mA USB A-D* *4-20mA USB A-D* *0-5V USB A-D* *0-10V USB A-D* *Thermistor USB A-D* *Temperature USB A-D*
*The ROI-XMA series is a versatile family of loop powered 4-20mA transmitters with built in sensor excitation. Signal ranges can be from mV to V*.	*The ROI-ISOV10 is a simple to use isolated signal conditioner. Galvanic isolation accomplished via capacitive barrier.*	*The ROI-USB is a simple to use general purpose USB analog to digital converter, powered by the* USB *port of Windows XP PC's.*

The ROI-XMA, ROI-USB, & ROI-ISOV all feature:
* Pluggable sensor Euro connectors
* Snap on base for DIN rail or surface mounting

ROI-XMA

Input sensor data, into your PLC or USB A-D; using standard:

4-20mA input A-D channels.
0-20mA input A-D channels.
0-5Vdc input A-D channels.
0-10Vdc input A-D channels.

No need to replace working sensors, you can signal condition your sensors to make them compatible with most modern industrial control systems.

Loop powered sensor 4-20mA transmitter, signal conditioner format; configured as:

Temperature transmitters, such as thermistor transmitters and RTD transmitters.
Position transmitters, such as potentiometer transmitters.
mV transmitters, to be used as bridge transmitters such as pressure transmitters.

The Robert Owen Inc. ROI-XMA 4-20mA sensor transmitter allows PLC Sensor Measurement. Read sensors with your PLC; using a 4-20mA sensor transmitter.

Useful for interfacing existing HVAC and refrigeration system Thermistor Temperature Sensors and RTD Temperature Sensors with modern industrial control systems. Works with PLC's featuring 4-20mA transmitter inputs. With ROI-XMA; you can use 10K ohm thermistors and 2252 ohm thermistors, either PTC or NTC, or the popular 100 ohm RTD or 1000 ohm RTD, with standard industrial PLC's and industrial I/O.

ROI-ISOV

The ROI-ISOV10 is a simple to use isolated signal conditioner.

Input and output sections powered by separate supplies.
Galvanic isolation accomplished via capacitive barrier.
Isolation level: 1.5Kv

USED IN LOOP ISOLATION
GROUND LOOP ELIMINATION
SIGNAL ISOLATION

High voltage measurement is easily & safely accomplished; when isolation amplifiers are added, to the input connections of a data converter.

When measured using voltage dividers alone; the possibility is always present, that improper grounding can result in equipment damage. The addition of isolation amplifiers to the plan, provides hundreds of volts of protection to the system, & the added benefit of ground loop elimination.

Isolation amplifiers protect the sensing equipment in those applications that need it, allowing an application to meet requirements with an added level of protection.

ROI-USB

Perform live analysis of your sensor data in your Excel spreadsheet.

Create charts and graphs that automatically update with data from your ROI-USB.

Bar charts, scatter plots, pie charts, all come alive with continuous temperature real time data added to them; with ROI-USB A-D‘s & Thermistor Temperature Sensors

PC powered by USB port measurement, configured for:

4-20mA input A-D channels.
0-20mA input A-D channels.
0-5Vdc input A-D channels.
0-10Vdc input A-D channels.

Compatible software tools, turn the USB-A-D's into Data Acquisition Systems. Software tools; turn Excel into a real time display and data acquisition program.

Read thermistors directly with your PC, using Microsoft Excel and Thermistor USB A-D's.

ROI-USB provides a real time MS Excel Thermistor Temperature Measurement Solution.

With ROI-USB and Microsoft Excel; you can create real time data trending and analysis, without specialized computer programming knowledge or software development packages. Input sensor data, from ROI-USB's, directly into Excel.

Collecting temperature data with your computer is about as simple as it gets. Simple to use Microsoft Excel, can now be configured directly by the user; as a custom data acquisition solution. For real time temperature trend plotting and active temperature profile measurement; use the ROI-USB, as a real time Excel Thermistor Temperature Measurement Solution.
